Pharmaceutical Blister Lidding Foil
Hard aluminium lidding foil for tablets, capsules and medical devices.
DB Packaging manufactures a range of hard aluminium foil suitable for blister packing of pharmaceutical products such as tablets, capsules and related preparations. Final product specifications are made as per the agreed contract with the customer.
- Hard temper aluminium for hygienic blister lidding
- Heat-seal coating suitable for PVC / PVDC coated PVC
- Printed or clear lacquer options to approved artwork
- Supplied with test certificates for observed parameters
DB Packaging parameters & tolerances.
General product specification. Final values are confirmed against the customer contract and batch documentation.
DB Packaging manufactures a range of hard aluminium foil suitable for blister packing of pharmaceutical products such as tablets, capsules and related preparations, with the following general specification. Final product specifications are made as per the agreed contract with the customer.
Standard Foil Gauge Options
| Standard Foil Gauge | Tolerance (+/- 8%) |
|---|---|
| 0.020 mm | +/- 0.0016 mm |
| 0.025 mm | +/- 0.002 mm |
| 0.030 mm | +/- 0.0024 mm |
Heat Seal Coating
Colourless vinyl resin (option for tinted resin available) conforming to applicable government regulations regarding direct contact with medicines and drugs. The resin is suitable for heat sealing to PVC / PVDC coated PVC films.
- (a) 4-6 GSM with a tolerance of +/- 0.5 GSM
- (b) 6-8 GSM with a tolerance of +/- 0.5 GSM. Standard, if not specified, heat sealing coating GSM is 4 with a tolerance of +/- 0.5.
Seal Strength with PVC / PVDC
Minimum seal strength measured against PVC / PVDC coated PVC films under recommended operating conditions.
Printing and Lacquer Coating
Printed as per text, layout and shade approved by the customer. For non-printed specification, clear lacquer is coated as a protective coating with good printability. Printing inks and lacquer coatings are capable of withstanding 180°C for 1 sec dwell time.
Configuration
Printed and unprinted blister foils are available in reel form. Unprinted blister foils are also available as jumbo rolls.
| Winding Direction | Generally printed or clear lacquer side is out, with heat seal coating inside. |
| Core | Material options: (a) Plastic (b) Aluminium (c) Cardboard. Core ID: 76 mm +/- 0.5 mm. Core length equals the width of the web. |
| Splices | Butt type made with 25 mm pressure sensitive tape. |
| Reel Outer Diameter | 250 +/- 10 mm for slit material, 400 +/- 10 mm for jumbos. |
| Reel Wander | Within +/- 1 mm. |
| Reel / Web Width | Plain: 45 mm to 800 mm (+/- 0.5 mm). Printed: 45 mm to 600 mm (+/- 0.5 mm). |
| Joints Per Reel | Maximum 2. Average less than 1. |
| Pin Holes | 0.025 and 0.030 mm foils are free from pin holes. In 0.020 mm foil, 40% of foil is free from pin holes; remainder less than 10 PSM. |
Identification
Each reel is identified with a sticker pasted inside the core with reel numbers, including specification, net weight, operator number and date of manufacture.
Packing
Blister foils are packed in cardboard cartons. Relevant markings are provided on each outer package.
Recommended Operating Conditions
- Sealing temperature170 to 180°C
- Sealing pressure2.8 to 5.6 kg/cm² (40 to 80 lbs/in²)
- Dwell time0.25 to 0.5 sec
Covering Area of 1 kg Finished Material (Nominal)
With 4 GSM nominal heat sealing coating. Values in Sq. M / Kg.
| Gauge & Temper | Sq. M / Kg |
|---|---|
| 0.020 (hard) | 17.18 |
| 0.025 (hard) | 13.94 |
| 0.030 (hard) | 11.72 |
Thickness Tolerances of Foil
| Gauge | Thick Min | Thick Nom | Thick Max | GSM Min | GSM Nom | GSM Max |
|---|---|---|---|---|---|---|
| 0.020 mm | 0.018 | 0.020 | 0.022 | 49.9 | 54.2 | 58.5 |
| 0.025 mm | 0.023 | 0.025 | 0.027 | 62.33 | 67.75 | 73.17 |
| 0.030 mm | 0.028 | 0.030 | 0.032 | 74.80 | 81.30 | 87.80 |
Thickness tolerance band: +/- 8% on nominal foil gauge.
